Troubleshooting the Test Set

Equipment Setup

1. Turn on the test set and the analyzer.
2. Preset the analyzer and set it to Standalone Mode. Select Utility > System >
3. Connect the RF cables to the analyzer's Ports 1 and 2. Connect the cables
4. Configure the analyzer to measure S21 and normalize the response trace.
5. Set the analyzer to Interface Control Mode: Select Channel > Hard ware Setup >
The <addrs>.<data> entries noted in the following Test Instructions table will be used
to configure the RF switches for this testing. After making your entry select <OK> to
execute the command, to return back for further entries, select Interface Control on
the PNA display.
Table 19 RF Signal Path Insertion Loss (S21)
RF Path Description
Source Out to Ports 3-12
A/B IN to Ports 3-12
Source Out to CPLR THRU
A/B IN to CPLR ARM
Keysight U3022AE10 User's and Service Guide
Configure > Multiport Capability. In the dialog box select Restart as a standalone
PNA > OK.
together using a 3.5 mm adapter.
More > Interface Control... and click Enable Interface Control box.
Signal
Source
Receiver
Source
Receiver
Insertion Loss (typical)
Figure 65 on page 82
Figure 66 on page 83 Figure 67 on page 84
or
Figure 68 on page 85
Figure 68 on page 85 or Figure 69 on page 86
81
