Service Information
Service Information
Refer to
No operator serviceable parts inside. Refer servicing to qualified personnel. To
prevent electrical shock do not remove covers.
These servicing instructions are for use by qualified personnel only. To avoid
electrical shock, do not perform any servicing unless you are qualified to do so.
Replaceable Parts
The following replaceable parts are available from Keysight Technologies "Find-A-
Part" system on the web at https://www.keysight.com/my/fapHomePage.
Table 17
The following replaceable parts may be ordered by sending an e-mail request
to ctd-soco_support@keysight.com. Be sure to include test set model, options,
and serial number. Some parts may have long lead times.
68
"Contacting Keysight" on page
Available Replacement Parts (SPO)
Description
PNA-X Test Set Rear Lock-link (right)
PNA-X Test Set Rear Lock-link (left)
PNA-L Test Set Lock-links
Coupler/Bridge
Coupler/Bridge (RoHS)
Amplifier (Option 001 & 002)
Amplifier (Option 001 & 002), (RoHS)
Bias Tee (Option 002)
Fuse (5 A 250 V non-time delay (20 mm)
Fuse (8 A 250 V non-time delay (1.25 inch)
DUT Control Board
Fan (rear panel)
RF Switch SP6T, 24 V, (RoHS)
94.
N5242-20138
N5242-20139
5063-9253
5087-7716
5087-7752
5087-7790
5087-7750
5087-7239
2110-0709
2110-0342
U3020-63223
87050-60027
87106-60065
Keysight U3022AE10 User's and Service Guide
Keysight Part
Number
