N5232A/B RF Interface Cable Connections
N5232A/B RF Interface Cable Connections
4-Port Analyzer
Figure 17 on page 28
cables have been supplied with kit (U3021-60015), see
Cable Connection Procedure
1. Remove the SOURCE OUT to CPLR THRU and RCVR IN to CPLR ARM jumpers (x4)
2. Connect the RF interconnect cables, supplied with this option, from the analyzer
Over torque will cause damage to the test set and may cause connectors to spin or
become loose.
Each end of the interconnect RF cables have a different length from the bend. When
connecting the RF Interconnect cables be sure that the longer end (from the bend) is
connected to the analyzer.
Keysight U3022AE10 User's and Service Guide
illustrates the cable configuration of the 4-Port analyzer. The
on the PNA-L. The RCVR R1 to SOURCE OUT reference loop jumpers (x1) remain
on the front panel.
to the test set. Torque each cable to 8 in-lb. Refer to
page
28.
Table 8 on page
28.
Table 8
and
Figure 17 on
27
