Address and Data Values
Address and Data Values
Setting the Test Port Paths with Address and Data
Refer to Table 11 below and
switch paths of the test set.
The address is the first value in the Test Set I/O control or GPIB data command. The
second value controls the source and receiver paths of the ports. To select a test set
port configuration both switches must be set to complete the source and receiver
paths. To do this you must add the data values together to determine the data
command value for each port, which is the second number in the Test Set I/O or GPIB
command. Refer to
on page
Example 1:
If the ports have the same address, only one command is needed.
Port 3 is the Source and Port 11 is the Receiver.
Source Port 3 = address 0, data 1 and Receiver Port 11 = address 0, data 80. The data
values are added together, the entry will be 0.81.
Example 2:
Refer to
If the ports have different addresses, two separate address data commands must be
used.
Port 7 is the Source and Port 8 is the Receiver
Source Port 7 = address 0, data 3 and Receiver Port 8 = address 16, data 48.
Two separate commands must to be sent, you may use the same dialog box. The
entry will be 0.3 in one command line, and 16.48 in the second line.
Table 11
Test Port Address and Data Values
Address
52
Figure 45 on page 53
"Interface Control Mode" on page 45
49.
Figure 45 on page
53.
Data
0
1
0
Ports
1
3
16
Ports
2
4
for information to set the internal
Source Path
2
3
4
5
0
5
7
9
11
1
6
8
10
12
2
Keysight U3022AE10 User's and Service Guide
and in
"SCPI Control Mode"
Receiver Path
16
32
48
64
80
3
5
7
9
11
4
6
8
10
12
