N5222A/B and N5242A/B RF Interface Cable Connections

N5222A/B and N5242A/B RF Interface Cable Connections
Figure 18
have been supplied with Cable Kit (U3021-60016).
1. Remove the SOURCE OUT to CPLR THRU and RCVR IN to CPLR ARM jumpers on
2. Add the front panel port labels to the analyzer. Refer to
3. Connect the RF interconnect cables from the analyzer to the test set in the order
Each end of the interconnect RF cables have a different length from the bend. When
connecting the RF Interconnect cables be sure that the longer end from the bend is
connected to the PNA.
Over torque will cause damage to the test set and may cause connectors to spin or
become loose.
Table 9 RF Interface Cable Connections (U3021-60016)
Numeric
Keysight U3022AE10 User's and Service Guide
illustrates the cable configuration of the test set to the analyzer. The cables
the analyzer. The RCVR R1-R4 to SOURCE OUT reference loop jumpers remain on
the front panel.
• Port 13 over Port 3 (U3022-80002)
• Port 14 over Port 4 (U3022-80003)
listed. As you are connecting each cable, torque to 8 in-lb. The longer, straight
end of each cable is connected to the test set. Refer to Table 9 below and
Figure 19 on page 30.
RF Cables
Order
1 U3042-20042
2 U3042-20043
3 U3042-20044
4 U3042-20045
5 U3042-20046
6 U3042-20047
7 U3042-20048
8 U3042-20049
From: Analyzer
Port 1, CPLR ARM
Port 1, SOURCE OUT
Port 1, RCVR A IN
Port 1, CPLR THRU
Port 2, CPLR THRU
Port 2, RCVR B IN
Port 2, SOURCE OUT
Port 2, CPLR ARM
Figure 19 on page 30.
To: Test Set
CPLR ARM
SOURCE OUT
A IN
CPLR THRU
CPLR THRU
B IN
SOURCE OUT
CPLR ARM
29
