U3022AE10
Available Options

Network Analyzer Interface Kit Options

The U3022AE10 requires one of the following kits to interface the test set with your
network analyzer. The interface kit model option includes the hard ware lock-link
and cable kit listed in Table 3.
Table 3 Interface Kit Options
12-Port System
N5222A/B Opt 201, 217 or
219 (PNA)
N5242A/B Opt 200 (PNA-X)
14-Port System
N5222A/B Opt 401, 417 or
419 (PNA)
N5232A/B Opt 416 (PNA-L)
N5242A/B Opt 400 (PNA-X)
a. Refer to
b. Refer to
c. Refer to
d. Refer to
Keysight U3022AE10 User's and Service Guide
Interface
Kit Option
U3021PN3-242
U3021PN3-242
Interface
Kit Option
U3021PN3-242
U3021PN3-430
U3021PN3-242
"Hardware Lock-link Kit Installation (U3021-60001)" on page 21
"N5232A/B RF Interface Cable Connections" on page 27
"Hardware Lock-link Kit Installation (U3021-60002)" on page 24
"N5222A/B and N5242A/B RF Interface Cable Connections" on page 29
Hard ware
Cable Kit - Conn. Type
Lock-link Kit
c
U3021-60002 U3021-60016, SMA m/m
c
U3021-60002 U3021-60016, SMA m/m
Hard ware
Cable Kit - Conn. Type
Lock-link Kit
c
U3021-60002 U3021-60016, SMA m/m
a
U3021-60001 U3021-60015, SMA m/m
c
U3021-60002 U3021-60016, SMA m/m
.
d
d
d
b
d
.
.
.
