U3022AE10
N5232A/B RF Interface Cable Connections
3.
Table 8 14-Port RF Cable Connections (U3021-60015)
RF Cables
U3022-20031
U3022-20032
U3022-20033
U3022-20034
U3022-20035
U3022-20036
U3022-20037
U3022-20038
Figure 19
14-Port Interface Connections
Figure 17
31
32
28
Add the front panel port labels from the cable kit (U3021-60015) over the
analyzer's port numbers.
• Port 13 over Port 2 (U3022-80002)
• Port 14 over Port 3 (U3022-80003)
•
Port 2 over Port 4 (U3022-80004)
From: Analyzer
SOURCE OUT
CPLR ARM
CPRL THRU
RCVR A IN
SOURCE OUT
CPLR ARM
CPRL THRU
RCVR D IN
indicates the final two digits of the part number for each cable.
34 33 Port 13
To: Test Set
SOURCE OUT
CPLR ARM
CPRL THRU
A IN
SOURCE OUT
CPLR ARM
CPRL THRU
B IN
Port 14 Port 2
Keysight U3022AE10 User's and Service Guide
38 37
35
36
