Device functions Proline Prosonic Flow 93C PROFIBUS DP/PA
Endress+Hauser
7.1.2

Function group OPERATION

→
INPUTS F
ACTUAL Use this function to view the current level of the status input.
STATUS INPUT
(5040) Display:
HIGH
LOW
SIMULATION Use this function to simulate the status input, i.e. to trigger the function (see Function
STATUS INPUT ASSIGN STATUS INPUT (5000) on Page 84) assigned to the status input.
(5041)
Options:
OFF
ON
Factory setting:
OFF
!
• The "SIMULATION STATUS INPUT" message indicates that simulation is active.
• The measuring device continues to measure while simulation is in progress, i.e. the
current measured values are output correctly via the other outputs.
"
The setting is not saved in the event of a power failure.
VALUE SIMULATION
!
STATUS INPUT
The function is not visible unless the SIMULATION STATUS INPUT function (5041) is
(5042)
active (= ON).
Use this function to define the level to be assumed at the status output during the
simulation. This value is used to test downstream devices and the measuring device
itself.
Options:
HIGH
LOW
Factory setting:
LOW
"
The setting is not saved in the event of a power failure.
STATUS INPUT
Functional description
INPUTS → STATUS INPUT → OPERATION
(only with PROFIBUS DP)
Note!
Caution!
Note!
Caution!
7 Block INPUTS
→
FAA CONFIGURATION
↓
OPERATION
500
504
85
