Device functions Proline Prosonic Flow 93C PROFIBUS DP/PA
Endress+Hauser
8.4.4

Function group CALIBRATION DATA

→
BASIC FUNCTION G
BASIC FUNCTION → SENSOR DATA (CH1 to CH2) → CALIBRATION DATA
P-FACTOR Use this function to display the P-factor.
(6890)
The P-factor describes the influence of the velocity distribution of the flow profile in
the pipe and depends on the Reynolds number. The P-factor is in the range from
0.98 to 1.02.
ZERO POINT Use this function to call up or manually change the zero point correction currently being
(6891) used.
User input:
5-digit floating-point number, including unit and sign (e.g. +1.0 ns)
Factory setting:
0.0 ns (no correction)
CORRECTION FACTOR Use this function to enter a correction factor at the client's site. It is advisable to only
(6893) enter values in the range from 0.5 to 2.
User input:
5-digit floating-point number (0.5 to 2)
Factory setting:
1.0000 (no correction)
PROFIBUS-DP GBA
(depends on PROFIBUS module)
PROFIBUS-PA GCA
↓
PROCESS PARAM. CH1 GIA
↓
PROCESS PARAM. CH2 GIB
↓
SYSTEM PARAM. CH1 GLA
↓
SYSTEM PARAM. CH2 GLB
↓
SENSOR DATA CH1 GNA
↓
SENSOR DATA CH2 GNB
Functional description
8 Block BASIC FUNCTION
→

CONFIGURATION

↓
MEASURING TUBE
↓
SENSOR PARAM.
↓

CALIBRATION DATA

→
CONFIGURATION
↓
MEASURING TUBE
↓
SENSOR PARAM.
↓
CALIBRATION DATA
680
681
688
689
680
681
688
689
107
