Max. Number Of Writes; Display Lines On The Local Display; Available Blocks, Groups, Etc - Endress+Hauser Proline Prosonic Flow 93C Description Of Device Functions

2 Function matrix
8
2.3

Max. number of writes

The number of writes to the EEPROM is technically restricted to a maximum of 1 million. Attention
must be paid to this limit since, if exceeded, it results in data loss and measuring device failure. For
this reason, avoid constantly writing nonvolatile device parameters via the PROFIBUS!
2.4

Display lines on the local display

The local display is split into various display lines.
Esc
+
-
E
Fig. 2: Local display
1 Main line
2 Additional line
3 Information line
The values are assigned to the individual lines in the USER INTERFACE block → Page 20.
2.5

Available Blocks, Groups, etc.

Type code of the
measuring device
93***-***********H X
93***-***********J –
93***-***********P –
93***-***********V –
Device functions Proline Prosonic Flow 93C PROFIBUS DP/PA
1
2
3
Available In-/Outputs
– – – – – –
X – – – – –
X X X – – X
X – – X X X
Available Blocks, Groups, etc.
OUTPUTS
X X X – – – –
X X X – – – –
X X X X X – –
X X X – – X X
Endress+Hauser
A0001253
– X X
– X X
X X X
X X X
