Device functions Proline Prosonic Flow 93C PROFIBUS DP/PA
Endress+Hauser
6.2.2

Function group OPERATION

→
OUTPUTS E
OUTPUTS→ PULSE/FREQUENCY OUTPUT 1 → OPERATION (FREQUENCY)
ACTUAL FREQUENCY
!
(4301)
This function is not available unless the FREQUENCY setting was selected in the
OPERATION MODE function (4200).
Use this function to view the computed value of the output frequency.
Display:
0 to 12500 Hz
SIMULATION
!
FREQUENCY
This function is not available unless the FREQUENCY setting was selected in the
(4302)
OPERATION MODE function (4200).
Use this function to activate simulation of the frequency output.
Options:
OFF
ON
Factory setting:
OFF
!
• The "SIMULATION FREQUENCY OUTPUT" message indicates that simulation is
• The measuring device continues to measure while simulation is in progress, i.e. the
"
The setting is not saved in the event of a power failure.
VALUE SIMULATION
!
FREQUENCY
This function is not available unless FREQUENCY was selected in the OPERATION
(4303)
MODE function (4200) and the SIMULATION FREQUENCY function (4302) is active
(= ON).
Use this function to define a selectable frequency value (e.g. 500 Hz) to be output at the
frequency output. This value is used to test downstream devices and the measuring
device itself.
User input:
0 to 12500 Hz
Factory setting:
0 Hz
"
The setting is not saved in the event of a power failure.
CURRENT OUTPUT 1
↓
PULSE/FREQ. 1 to 2
Functional description
(only with PROFIBUS DP)
Note!
Note!
Note!
active.
current measured values are output correctly via the other outputs.
Caution!
Note!
Caution!
6 Block OUTPUTS
EAA
→
ECA CONFIGURATION
↓
OPERATION
420
430
69
