7 Block INPUTS
86
7.1.3
Function group INFORMATION
→
INPUTS
F
TERMINAL NO.
Use this function to display the numbers of the terminals (in the connection
(5080)
compartment) which are used by the status input.
Display:
24 (+) / 25 (–)
Device functions Proline Prosonic Flow 93C PROFIBUS DP/PA
STATUS INPUT
FAA
Functional description
INPUTS → STATUS INPUT → INFORMATION
(only with PROFIBUS DP)
→
CONFIGURATION
↓
OPERATION
↓
INFORMATION
Endress+Hauser
500
504
508
