8 Block BASIC FUNCTION
104
8.4.2

Function group MEASURING TUBE

→
BASIC FUNCTION G
BASIC FUNCTION → SENSOR DATA (CH1 to CH2) → MEASURING TUBE
PIPE STANDARD Use this function to view the pipe standard for the measuring pipe.
(6810)
Factory setting:
Depends on the measuring pipe
NOMINAL DIAMETER Use this function to view the nominal diameter of the measuring pipe.
(6811)
Factory setting:
Depends on the measuring pipe
PIPE DIAMETER (6812) Use this function to view the pipe outer diameter of the measuring pipe.
Display:
5-digit floating-point number (incl. unit)
Factory setting:
Depends on the measuring pipe
WALL THICKNESS Use this function to view the wall thickness of the measuring pipe.
(6813)
Display:
4-digit floating-point number (incl. unit)
Factory setting:
Depends on the measuring pipe
Device functions Proline Prosonic Flow 93C PROFIBUS DP/PA
PROFIBUS-DP GBA
(depends on PROFIBUS module)
PROFIBUS-PA GCA
↓
PROCESS PARAMETER
GIA
CH1
↓
PROCESS PARAMETER
GIB
CH2
↓
SYSTEM PARAMETER
GLA
CH1
↓
SYSTEM PARAMETER
GLB
CH2
↓
SENSOR DATA CH1 GNA
↓
SENSOR DATA CH2 GNB
Functional description
→

CONFIGURATION

↓

MEASURING TUBE

→
CONFIGURATION
↓
MEASURING TUBE
Endress+Hauser
680
681
680
681
