FIGURE 22. Tilt Calibration Screen
5. Select Start Calibration. The following screen will appear:
FIGURE 23. Calibration in Progress Screen
NOTE:
The calibration may take a few minutes to complete.
FIGURE 24. Machine Orientation After Tilt Calibration
P/N 016-0171-277 Rev. L
VIPER PRO CALIBRATION AND OPERATION
87
