SMARTRAX SUPPLEMENT
INSTALLATION MANUAL
AG CHEM 1903 TERRAGATOR
117-0190-037

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the smartrax and is the answer not in the manual?

Questions and answers

Summary of Contents for Raven smartrax

  • Page 1 SMARTRAX SUPPLEMENT INSTALLATION MANUAL AG CHEM 1903 TERRAGATOR 117-0190-037...
  • Page 2 Raven Industries shall not be responsible or liable for incidental or consequential damages or a loss of anticipated benefits or profits, work stoppage or loss or impairment of data arising out of the use or inability to use the Smartrax or any of its components.
  • Page 3 RAVEN INDUSTRIES LIMITED WARRANTY WHAT IS COVERED? This warranty covers all defects in workmanship or materials in your Raven Flow Control Product under normal use, maintenance, and service. HOW LONG IS THE COVERAGE PERIOD? This warranty coverage runs for 12 months from the purchase date of your Raven Flow Control Product.
  • Page 4 RAVEN INDUSTRIES FLOW CONTROL DIVISION 205 East Sixth Street - P.O. Box 5107 - Sioux Falls, South Dakota 57117-5107 E-mail: fcdinfo@ravenind.com www.ravenprecision.com Toll-free: 800-243-5435 - Fax: 605-331-0426 Supplement Installation Manual, Ag Chem 1903 Terragator #016-0190-037 Rev A 08/04...
  • Page 5: Table Of Contents

    016-0190-037 TABLE OF CONTENTS 08/04 1903 without POWER BEYOND ......................2 MOUNTING THE UNIVERSAL BRACKET ..................2 MOUNTING THE STEERING POSITION SENSOR ................2 MOUNTING THE HYDRAULIC VALVE ....................3 MOUNTING THE PRESSURE SWITCH ..................... 3 HOSE CONNECTIONS AND ROUTING ..................... 4 PRESSURE HOSE ........................
  • Page 6: 1903 Without Power Beyond

    1903 without POWER BEYOND MOUNTING THE UNIVERSAL BRACKET Position the bracket on the steel support beam beneath the frame under the cab. Drill holes to fit the mounting bracket pattern and attach the universal mounting bracket to the machine. Figure below shows the bracket mounted to the machine with the valve and hoses attached.
  • Page 7: Mounting The Hydraulic Valve

    MOUNTING THE HYDRAULIC VALVE Position the hydraulic valve on the universal bracket over the top of the proper hole pattern. Secure the valve to the bracket using the provided metric bolts and lock washers. MOUNTING THE PRESSURE SWITCH Connect the pressure switch to the steering assist valve port marked “PS”. Pressure Switch...
  • Page 8: Hose Connections And Routing

    HOSE CONNECTIONS AND ROUTING Hose routing from steering assist valve to steering orbital...
  • Page 9: Pressure Hose

    Re-connect the original hose to the tee fitting. Connect one end of the supplied tank hose to the “T” port on the Raven steering control valve and the other end to the remaining open port to the tee on the orbital.
  • Page 10: Right Steer Hose

    Right Steer Hose Remove the hose attached to the right steer port of the orbital and attach a provided 3/4” tee fitting to the orbital. Re-connect the hose to the tee fitting. Connect one end of the supplied right steer hose to the open port on the tee and the other end to the “B”...
  • Page 11: 1903 With Power Beyond

    1903 with POWER BEYOND MOUNTING THE UNIVERSAL BRACKET Position the bracket on the steel support beam beneath the frame under the cab. Drill holes to fit the mounting bracket pattern and attach the universal mounting bracket to the machine. Figure below shows the bracket mounted to the machine with the valve and hoses attached.
  • Page 12: Mounting The Hydraulic Valve

    MOUNTING THE HYDRAULIC VALVE Position the hydraulic valve on the universal bracket over the top of the proper hole pattern. Secure the valve to the bracket using the provided metric bolts and lock washers. MOUNTING THE COUNTERBALANCE VALVE, PRESSURE SWITCH, and NEEDLE VALVE NOTE: A new bracket must be fabricated to attach the counterbalance valve to the machine.
  • Page 13: Pressure Hose

    Supplied tee - Supplied tee and Supplied tee - After removing the pressure Supplied hose elbow - supplied Supplied hose hose, connect the supplied 90 runs to B-Port hose runs to tank runs to A-Port elbow. The pressure port hose on steering port on steering on steering...
  • Page 14: Cb To Left Steer Hose

    Supplied tee - Supplied tee and Supplied 90 elbow Supplied tee - Supplied hose elbow - supplied connected to pressure Supplied hose runs to B-Port hose runs to tank port, hose connects to runs to A-Port EF port on steering on steering on steering port on steering...
