INITIAL STARTUP

DATA TRANSFER

During the initial startup of the SmarTrax system, language data must transfer from the SmarTrax node to the CR7.
Allow several minutes for the data transfer to complete before calibrating SmarTrax.
NOTE: The Rx and Tx diagnostic LEDs on the SmarTrax node will flash rapidly during the data transfer. The Rx
and Tx lights will flash slowly or turn off when the data transfer is complete. Attempting to access the
SmarTrax configuration screen while language data is transferring will open a message asking the
user to try again later.

GPS CONFIGURATION

NOTE: The SmarTrax system will automatically attempt to detect GPS position information and will proceed
with the calibration wizard if GPS is present. If GPS messages cannot be detected, a GPS error
message will be displayed. Check any external receiver connections and verify settings on external
GPS equipment. Contact your local Raven dealer for additional assistance if the SmarTrax system still
does not detect a GPS message.
12
Message
Increase - Allows the indicated value to be manually
adjusted incrementally.
Decrease - Allows the indicated value to be manually
adjusted incrementally.
Accept - Saves the changes made to the SmarTrax
system at the end of the setup process and returns the
to the Tools Menu.
Exit - Exits from the current screen without saving any
changes made to the system.
