C 4
HAPTER
Display
NOTE: Refer to Error Messages section on page 134 for additional status conditions which may be displayed
in the SmarTrax on-screen widget.

INITIAL STARTUP

DATA TRANSFER

During the initial startup of the SmarTrax system, language data must transfer from the SmarTrax node to the
Viper 4. Allow several minutes for data transfer to complete before calibrating SmarTrax.
NOTE: The Rx and Tx diagnostic LEDs on the SmarTrax node will flash rapidly during the data transfer. The Rx
and TX lights will flash slowly or turn off when the data transfer is complete. Attempting to access the
SmartTrax configuration screen while language data is transferring will open a message asking the
user to try again later.

GPS CONFIGURATION

NOTE: The SmarTrax system will automatically attempt to detect GPS position information and will proceed
with the calibration wizard if GPS is present. If GPS messages cannot be detected, a GPS error
message will be displayed. Check any external receiver connections and verify settings in any external
GPS equipment. Contact your local Raven dealer for additional assistance if the SmarTrax system still
does not detect a GPS message.

INTERNAL GPS RECEIVER

NOTE: The steps below apply only to Viper 4 computers with an internal GPS receiver that is being used as
the primary GPS source.
38
Message
Accept - Saves the changes made to the SmarTrax
system at the end of the setup process and returns the
to the Tools Menu.
Exit - Exits from the current screen without saving any
changes made to the system.
SmarTrax™ Calibration & Operation Manual
