Message
Vlve Flt
Wrong HDW
XDucer Er
Yaw Error

SMARTRAX OPERATION

Problem
SmarTrax will not power up.
136
Possible Cause
Communication could not be established
with the Steering Ready ISO valve.
The software and hardware versions of
the node are not compatible.
A problem with the pressure transducer
or cabling has been detected.
Yaw rate sensor values are out of range.
Possible Cause
The power connections are loose
or not properly connected.
The fuse is blown.
The battery connections are loose,
corroded, or not properly
connected.
The machine does not have proper
voltage to run the system.
The field computer or cabling is
defective.
Corrective Action
Verify the proper software version is
installed on the machine's ISO CANbus.
Verify that the system is connected to a
Raven-supported, ISO-compatible valve.
Update the node software to the proper
version.
Verify the PSI values on the System
Diagnostics screen.
Verify pressure transducer connection
and cabling.
Replace the transducer(s).
Replace the SmarTrax node.
Corrective Action
Check the power connections to
ensure they are secure and
properly connected.
Replace the fuse.
Check the battery connections to
ensure they are secure and
properly connected.
Test for +12VDC using a voltmeter.
• Test the cable voltage from the
field computer to the node.
• Replace the field computer.
