FIGURE 1. Serial Device Setup Screen
1. Select Serial Port from the CR7 main menu.
2. Select the appropriate serial device tab on the left side of the screen.
3. Verify that SmarTrax is listed in the Device/Device Type field.
NOTE: If SmarTrax is not listed, press the
still do not appear, inspect cable connections to ensure they are installed securely, then press the
Detect Device
further information.
4. Press Accept.

SMARTRAX TERMS OF USE

FIGURE 2. Operator Liability Warning Screen
1. Select SmarTrax.
2. Read the SmarTrax Liability Waiver.
3. Select Yes, I agree.
NOTE: If the operator does not accept liability, the SmarTrax system will disable and cannot be re-engaged
until the liability waiver is accepted. The SmarTrax Liability Waiver screen will appear each time the
CR7 is turned on.
P/N 016-0171-277 Rev. L
Detect Device
button again. If the devices still do not appear, refer to Chapter 7, Troubleshooting for
CR7 CALIBRATION AND OPERATION
button in the middle of the screen. If these devices
13
