Raven SmarTrax Calibration And Operation Manual page 143

Problem
SmarTrax will not engage by
pressing the foot/enable switch.
SmarTrax will not disengage when
the steering wheel is turned.
SmarTrax will disengage only when
the steering wheel is turned one
way.
The wheels turn the wrong way
when the steering wheel is turned.
Valve makes noise in stand-by
mode.
Valve makes noise all of the time.
P/N 016-0171-277 Rev. L
Possible Cause
The node is not communicating
properly.
There is an error in the SmarTrax
system.
The steer switch override is active.
The foot/enable switch cable is not
connected or is faulty.
The Disengage Setting is incorrect.
The knob on the pressure switch is
turned in too far. (SmarTrax
hydraulic valve part numbers 334-
0003-056 through 334-0003-079
only)
The pressure disengage switch has
failed.
The flow disengage switch has
failed on one side.
The hydraulic hose connections
are reversed.
The pressure relief adjustment on
the SmarTrax valve is set
incorrectly.
The load sense orifice in the valve
is plugged.
The incorrect SmarTrax valve is
installed.
TROUBLESHOOTING
Corrective Action
Check the LEDs on the node to
ensure proper communication.
Identify and correct system errors.
Test the voltage (12V) and ground
at the disengage switch and
pressure transducers.
Adjust the disengage settings and/
or pressure switch knob.
• Replace the pressure switch.
• Replace the flow disengage
switch.
• Replace the transducer.
Test the voltage (12V) and ground
on the foot/enable switch cable
connection, using a jumper wire to
simulate foot/enable switch
function.
Adjust the Disengage Setting in
the field computer.
Turn the knob on the pressure
switch out.
Replace the faulty pressure
disengage switch.
Replace the faulty flow disengage
switch.
Reverse the left and right steering
hoses on the machine's steering
orbital.
Adjust the relief valve on the
SmarTrax valve until the noise
stops.
Inspect the load sense orifice for
blockage.
Install the SmarTrax hydraulic valve
recommended for the machine
being used.
