IC-KP2-2HB18-2V1
Commands
7.1.2

Command examples

Note!
Enter all commands without spaces!
1. Example: Set tag type
Tag type "99" is preset on delivery. The tag type is used which is stored on the
R/W head.
Send the command Change tag described in the Command table to select the
tag type IPC03 for the R/W head connected to channel 1.
You should receive one of the responses described in the Response table.
Command:
CT 1 03 # <CR>
CT
1
03
#
<CR>
There is a read/write tag in the detection range.
Response:
0 0 04 1 000 # <CR>
0
0
04
1
000
#
<CR>
The response indicates that the R/W head on channel 1 has received the
command (status = '0').
Further possible responses:
4 0 04 1 000 # CR = wrong tag type
6 0 04 1 000 # CR = no R/W head is connected
26
Change tag command
Channel 1
Tag type IPC03
End character
End character
Status
Reserved
Command code
Channel 1
Response length in bytes
End character
End character
