IC-KP2-2HB18-2V1

Technical specifications

Mechanical specifications

Protection degree

Connection

Material

Housing

Installation

Mass

IP67

Read/write heads: shielded, 4-pin, M12 connector

Power supply: M12 connector

Protective earth: M4 earthing screw

Diagnostic RS 232: M8 connector

CC-Link: M12 connector, A-coded

Powder coated zinc

screw fixing

approx. 500 g
