IC-KP2-2HB18-2V1
Commands
2. Example: Writing two double words from address 7 with R/W head on
channel 1
1. Position an IPC03 read/write tag in front of the R/W head on channel 1.
2. Send the command single write words as described in the Command
table.
Command:
SW 1 0007 02 ABCDEFGH # <CR>
SW
1
0007
02
ABCDEFGH
#
<CR>
There is a read/write tag in the detection range.
Response:
0 0 40 1 000 # <CR>
0
0
40
1
000
#
<CR>
If a read/write tag is not within the detection range, you will receive the response 5
0 40 1 000 #<CR>. The two double words cannot be written (read/write tag is not
within the detection range): Status = '5').
Response:
5 0 40 1 000 # <CR>
5
0
40
1
000
#
<CR>
28
Single write words command
Channel 1
Address (in hexadecimal format)
Number of double words (4-byte words)
Data
End character
End character
Status
Reserved
Command code
Channel 1
Response length in bytes
End character
End character
Status
Reserved
Command code
Channel 1
Response length in bytes
End character
End character
