IC-KP2-2HB18-2V1
Commands
Tag type P+F
designation
High Low
byte byte
'7' '6'
IUC76
'8' '0' -
'9' '9' Depends on
the reader
IQC20 is not an actual tag type as such, but is used to read the UID (read only code) of all ISO 15693
1)
compliant read/write tags.
Read/write tag IQC33 can only be used in combination with a IQH1-... read/write head. The memory is
2)
divided into 8-byte blocks (instead of 4-byte blocks). You must enter a continuous initial address for write
commands SR, ER, SW and EW.
<WordNum> specifies the number of 4-byte blocks (here, max. 48) and must be an even number.
Read/write tag IQC37 can only be used in combination with a IQH1-... read/write head. The memory is
3)
divided into 32-byte blocks (instead of 4-byte blocks). You must enter a continuous initial address for
write commands SR, ER, SW and EW.
<WordNum> specifies the number of 4-byte blocks (here, max. 48) and must be divisible by 8.
Read/write tags IQC40–IQC43 can only be used in combination with a IQH2-... read/write head.
4)
<WordNum> specifies the number of 16-byte blocks and must be a multiple of 4.
The memor y can be encrypted for each sector (1 sector = 4 blocks of 16 bytes).
The default key in the tag and reader is FF FF FF FF FF FF
using the Read param command and written using the Write param command (see System
Commands). The key is only changed in the reader during this process and not in the tag!
The key in the reader is stored in the non-volatile memory.
IUC7* type read/write tags can only be used with read/write head IUH-F117-V1 in combination with
5)
certain control interfaces.
The tag type configured in the read/write head as the default is selected.
6)
Read/write tags can have 4-byte (older versions) or 7-byte UIDs. IQC42 and IQC43 type read/write tags
7)
from Pepperl+Fuchs generally have 7-byte UIDs.
Note!
In a plant where only one tag type is used, it is advantageous to permanently
configure that tag type so that the read/write head detects the tag quicker.
Default tag type:
In the factory default condition, the tag type 99 is preset in the IDENTControl
(depending on the reading head type), thus the tag type preset on the reading
head is used.
