IC-KP2-2HB18-2V1
Commands
Slave -> master
Address
CH1
RWr n+9
RWr n+A
RWr n+B
RWr n+C
RWr n+D
RWr n+E
RWr n+F
n:
*:
7.3.4

Initialization

There are three ways of changing the settings of the IC-KP2-2HB18-2V1:
■
■
■
Initial data processing can be skipped when the RYn0 signal initial setting
value is set to 1. The IC-KP2-2HB18-2V1 then uses the parameter from the
nonvolatile memory for initialization. If RYn0 is set to 1 while the initial data
completesignal is set to 1, it is not necessary to send parameters to RWw, as the
RWw memory is not used.
Changing the setup with a system command is described in the following
sections, see chapter 7.3.8. Both initial data processing as well as initial data
setting correspond to the definition in the CC-Link specification.
Note!
Error flags
The error status flag is set if an error status occurs when setting or processing
initial data that does not equal 0 or 6.
Initial data processing
RX(m+n)8/RY(m+n)8: initial data processing signal request/termination
If the slave is switched on or after a hardware reset, initial data processing is
requested on this signal.
Note: linked with (RX(m+n)B (Remote Monitor ready).
36
Bit no.
CH2* 15
Address in master module, specified by the assignment of the stations
In dual-channel mode
The control interface triggers initial data processing, after which a data
link is established.
The higher-level bus triggers initial data setting during operation.
A system command is sent during operation
8 7
<Read data>
<Read data>
<Read data>
<Read data>
<Read data>
<Read data>
<Read data>
0
