IC-KP2-2HB18-2V1
Product Description
4.4

Range of application

The system is suited for the following applications:
Automation
■
Material flow control in production
■
Acquisition of operating data
■
Access control
■
Identification of storage vessels, pallets, work piece carriers, refuse
■
containers, tanks, containers, etc.
4.5

Device characteristics

Up to 2 R/W heads can be connected
■
Alternatively, 1 R/W head and 1 trigger sensor can be connected
■
LED status indicators for bus communication and R/W heads
■
4.6

Interfaces and connections

The control unit IC-KP2-2HB18-2V1 has the following interfaces and connections:
socket at housing
5
4
Figure 4.6
read/write head
1
1 +
2 A
3 -
2
4 B
5
trigger sensor
3
+
signal
-
trigger switch
5
4
CC-Link out
voltage
2
supply
RS 232
3
2
CC-Link in
1
2
3
1
4
3
4
1
1
4
3
