IC-KP2-2HB18-2V1
Commands
Slave -> Master (RX)
Address
RX(n+7)0
RX(n+7)1
RX(n+7)2
RX(n+7)3
RX(n+7)4
RX(n+7)5
RX(n+7)6
RX(n+7)7
RX(n+7)8
RX(n+7)9
RX(n+7)A
RX(n+7)B
RX(n+7)C
RX(n+7)D
RX(n+7)E
RX(n+7)F
n:
System area addresses
CC-Link version:
V 1.10
Cyclic setting:
-
Master address:
RX(n+7)0..F
Slave address:
RY(n+7)0..F
Signal name
unavailable
Initial data processing
request flag
Initial data setting
complete flag
Error status flag
Remote READY
unavailable
Address in master module, specified by the assignment of the stations
V 2
single
RX(n+7)0..F
RY(n+7)0..F
Master -> Slave (RY)
Address
Signal name
RY(n+7)0
unavailable
RY(n+7)1
RY(n+7)2
RY(n+7)3
RY(n+7)4
RY(n+7)5
RY(n+7)6
RY(n+7)7
RY(n+7)8
Initial data processing
complete flag
RY(n+7)9
Initial data setting request
flag
RY(n+7)A
Error reset request flag
RY(n+7)B
unavailable
RY(n+7)C
RY(n+7)D
RY(n+7)E
RY(n+7)F
V 2
V 2
2-way
4-way
RX(n+D)0..F
RX(n+1B)0..F
RY(n+D)0..F
RY(n+1B)0..F
V 2
8-way
RX(n+37)0..F
RY(n+37)0..F
31
