IC-KP2-2HB18-2V1
Installation
CC-Link version
Version 1.1 and
Version 2 - single
extension
Version 2 - dual
extension
Version 2 -
quadruple
extension
Version 2 - octuple
extension
<WordNum> = 8 bit, word count that can be read or written, the number is
described in hexadecimal from 0h to FFh. The word count can be smaller if a
transponder or R/W head only supports a small number of words.
The following is valid for IPC03: Set the word count <WordNum> to 0h, if you want
to read the preset data range of a read/write tag at address 0000h ( "Default
Read").
The following is valid for IQC33: <WordNum> specifies the number of 8-byte
blocks (max. 7 here) and must be an even number.
CC-Link
Physical interface:
Protocol:
Transfer rate:
CC-Link IN: M12 plug, A-coded
Connector
assignment
2
20
Maximum word count
<WordNum> <= 3 (0000 0011b)
<WordNum> <= 7 (0000 0111b)
<WordNum> <= 7 (0000 0111b)
<WordNum> <= 15 (0000 1111b)
<WordNum> <= 15 (0000 1111b)
<WordNum> <= 31 (0001 1111b)
<WordNum> <= 31 (0001 1111b)
<WordNum> <= 63 (0011 1111b)
RS-485
CC-Link
156 kbit/s
625 kbit/s
2.5 Mbit/s
5 Mbit/s
10 Mbit/s
Pin
1
1
2
3
4
4
3
Transmission
per channel with parallel
transfer of channels 1 & 2
per channel with transfer of
channel 1
per channel with parallel
transfer of channels 1 & 2
per channel with transfer of
channel 1
per channel with parallel
transfer of channels 1 & 2
per channel with transfer of
channel 1
per channel with parallel
transfer of channels 1 & 2
per channel with transfer of
channel 1
Signal Description
SLD Screen
DB (white) Data B
DG (yellow) Grounding
DA (blue) Data A
