IC-KP2-2HB18-2V1
Commands
Slave -> Master
Address
CH1
RWr n
RWr n+1
n:
*:
The R/W head attempts to write a word in the configuration range to the address
<ConfAddr> until successful. After each write, the status is evaluated and the
system waits until a new data carrier is within the detection range. The command
then starts again from the beginning. In order to write in the configuration range,
the password mode must be active.
The status '05h' (read/write command) is only output when a data carrier leaves
the detection range or is not yet within the detection range when the command is
executed.
If two data carriers enter the read range one immediately after the other, the status
'05h' is not issued between the two readings.
7.3.11 Special commands for read/write tags IPC11, IDC-...-1K, IQC-...

and IUC...

Write read only code IPC11 and IDC-..-1K
"Read-after-write" operating mode is not used.
Tags IPC11 can be programmed to behave like the IPC02 read only tag. To do
this, use the commands SX and EX. The code is read when tag type '02' or '11' is
set with the commands SF and EF.
Tags IDC-...- 1K can be programmed to behave like the ICC read only tag. This
programming occupies the first 8 bytes in the tag and occurs when the tag type
'50' is set with the commands SX or EX.
This code is read when tag type '52' is set with the commands SF or EF. If you use
the command SF or EF when tag type '50' is selected, the 4-byte read only code
of the tag is issued.
Single write read only code (SX --> 1Fh)
Master -> Slave
Address
CH1
RWw n
RWw n+1
RWw n+2
Bit no.
CH2* 15
RWr n+8 <WordNum>
RWr n+9 <ReplyCounter>
Address in master module, specified by the assignment of the stations
2 channel mode
Bit no.
CH2* 15
RWw n+8
RWw n+9 <FixType> (low byte)
RWw n+A
8 7
0
8 7
<FixLen> 0
<Data>
0
1 1 0 0 1 1 0
<Status>
0
0 0 1 1 1 1 1
<FixType> (high byte)
<Data> (high byte)
