IC-KP2-2HB18-2V1
Commands
Slave -> Master
Address
CH1
RWr n+2
RWr n+3
RWr n+4
n:
Address in master module, specified by the assignment of the stations
*:
2 channel mode
The R/W head attempts to read a special read only code until successful. Only
data that changes is transferred via the interface, i.e. the R/W head transfers data
whenever it reads a new data carrier or whenever it reads a data carrier where
there was previously no R/W head within the detection range.
The status '05h' (read command) is output whenever a data carrier leaves the
detection range.
Note!
The <FixLen> of IDC-...-1K read/write tags is always 6 bytes.
Bit no.
CH2*
15
RWr n+A
<ID code>
RWr n+B
<ID code>
RWr n+C
<ID code> (low byte)
8
7
<ID code> (high byte)
<ID code>
<ID code>
0
75
