IC-KP2-2HB18-2V1
Commands
Single write words (SW --> 40h)
Master -> Slave
Address
CH1
RWw n
RWw n+1
RWw n+2
RWw n+3
RWw n+4
RWw n+5
RWw n+6
RWw n+7
RWw n+8
RWw n+9
RWw n+A
RWw n+B
RWw n+C
RWw n+D
RWw n+E
RWw n+F
Slave -> Master
Address
CH1
RWr n
RWr n+1
n:
*:
The command writes the number of words <WordNum> at the address
<WordAddr> once.
60
Bit no.
CH2* 15
RWw n+8 <WordNum>
RWw n+9 <WordAddr> low byte
RWw n+A <Write data> byte 2
RWw n+B <Write data> byte 0
RWw n+C <Write data> byte 2
RWw n+D <Write data> byte 0
RWw n+E <Write data> byte 2
RWw n+F <Write data> byte 0
<Write data> byte 2
<Write data> byte 0
<Write data> byte 2
<Write data> byte 0
<Write data> byte 2
<Write data> byte 0
<Write data> byte 2
<Write data> byte 0
Bit no.
CH2* 15
RWr n+8 <WordNum>
RWr n+9 <ReplyCounter>
Address in master module, specified by the assignment of the stations
2 channel mode
8 7
0 1 0 0 0 0
<WordAddr> high byte
<Write data> byte 3
<Write data> byte 1
<Write data> byte 3
<Write data> byte 1
<Write data> byte 3
<Write data> byte 1
<Write data> byte 3
<Write data> byte 1
<Write data> byte 3
<Write data> byte 1
<Write data> byte 3
<Write data> byte 1
<Write data> byte 3
<Write data> byte 1
8 7
0 1 0 0 0 0
<Status>
0
0 0
0
0 0
