IC-KP2-2HB18-2V1
Commands
Read data
Command
code
16d 10h
25d 19h
Write data
Command
code
64d 40h
26d 1Ah
Special command modes
Password mode with IPC03
Command
code
24d 18h
65d 41h
66d 42h
IPC03 configuration
Command
code
97d 61h
104d 68h
18d 12h
102d 66h
Write read only code IPC11 and IDC-...-1K
Command
code
31d 1Fh
36d 24h
Extended commands for type IDC-...-1K and IUC... tags
Command
code
10d 0Ah
113d 71h
13d 0Dh
Command description
See "Single read words (SR --> 10h)" on page 56
See "Enhanced read words (ER --> 19h)" on page 58
Command description
See "Single write words (SW --> 40h)" on page 60
See "Enhanced write words (EW --> 1Ah)" on page 62
Command description
See "Set password mode (PM --> 18h)" on page 64
See "Change password (PC --> 41h)" on page 65
See "Set password (PS --> 42h)" on page 66
Command description
See "Single get configuration (SG --> 61h)" on page 68
See "Enhanced get configuration (EG --> 68h)" on page 69
See "Single write configuration (SC --> 12h)" on page 70
See "Enhanced buffered write configuration (EC --> 66h)" on page 70
Command description
See "Single write read only code (SX --> 1Fh)" on page 71
See "Enhanced buffered write read only code (EX --> 24h)" on page 73
Command description
See "Single read special read only code (SS --> 0Ah)" on page 74
See "Enhanced read special read only code (ES --> 71h)" on page 74
See "Single program special read only code (SP --> 0Dh)" on page 76
Abbre
viation
SR
ER
Abbre
viation
SW
EW
Abbre
viation
PM
PC
PS
Abbre
viation
SG
EG
SC
EC
Abbre
viation
SX
EX
Abbre
viation
SS
ES
SP
45
