Commissioning

6 Commissioning
6.1

Connection

Warning!
Incorrect electrical connection
Incorrect connections may damage the system.
Before commissioning, familiarize yourself with the system of communication
between your CC-Link master and the R/W system. Check all connections before
commissioning.
When the supply voltage is connected and the device is initialized, the PWR/ERR
LED lights up green. If the LED lights up red, either the initialization process has
not yet finished or there is a device fault.
6.2

Device settings

Caution!
Device not configured or configured incorrectly
System failure caused by incorrectly configured device
Configure the device prior to commissioning.
You must set the various parameters prior to commissioning.
6.2.1

Address setting

Assign the IDENTControl Compact an address between 01 and 64 that is not
already assigned to another node. Set the device addresses with station no.
rotary switches on the rear of the housing. The addressing via the device address
is consistent with CC-Link. Select the next free device address in the CC-Link
network as a device address.
Note!
The setting of the address is only read during the start process. An alteration of
the switches during operation makes no alteration to the configuration of the
IDENTControl control interface. If you change the address during operation, LED
L ERR flashes red. To apply the changes, switch the device off and back on again.
