Commands
LED 1 on the IDENTControl Compact and the LED on the R/W head briefly light
up green when the reading command is activated and then yellow if the command
is executed successfully.
3. Example: Reading two double words from address 7 with R/W head
on channel 1
1. Send the read command Enhanced buffered read words described in the
Command table.
2. Move a read/write tag into the detection range. The R/W head reads the data
on the read/write tag. You should receive the responses described in the
Response table.
Command:
ER 1 0007 02 # <CR>
ER
1
0007
02
#
<CR>
Response:
0 0 19 1 008 ABCDEFGH # <CR
0
0
19
1
008
ABCDEFGH
#
<CR>
7.2

General CC-Link information

CC-Link is a standardized field bus, which enables data exchange between PLCs,
PCs, operating and observation devices and also sensors and actuators.
Note!
The CC-Link Partner Association (CLPA) publishes informational brochures and a
CC-Link product catalog (http://www.clpa-europe.com/).
Enhanced buffered read words command
Channel 1
Address (in hexadecimal format)
Number of double words
End character
End character
Status
Reserved
Command code
Channel 1
Response length in bytes
Data
End character
End character
