IC-KP2-2HB18-2V1
Commands
<IdentChannel>
<IdentChannel>
<IdentChannel>
Table 7.1
<Mode>
<Mode>
<Mode>
Activating trigger mode interrupts a command running on <IdentChannel>.
The channel to which the command telegram is transferred is automatically the
<SensorChannel> channel. The trigger sensor is connected to the
<SensorChannel>.
If trigger mode is activated with <Triggermode>=1 (=2), dampening the trigger
sensor generates the status 0 (5) and after changing to undamped state,
generates the status 5 (0) as a response to <Sensorchannel>. Activating trigger
mode generates a response that includes the current status of the sensor on
<SensorChannel>.
If a read/write command is sent to the triggered channel <IdentChannel> when
trigger mode is active, this command is always activated if <SensorChannel>
transmits status 0. <IdentChannel> transmits status 0 to confirm receipt of this
command.
The command activated by <SensorChannel> initiates execution of the command
as if it had just been restarted by the host.
The command is deactivated again if the status of <SensorChannel> changes to
5 or trigger mode is deactivated.
If you set <IdentChannel>=0, the sensor signal is transferred to <SensorChannel>
without influencing a reader.
<IdentChannel>=0 allows you to assign the trigger signal to channel '0'. This
means that the trigger signal is transmitted to the controller and not to a reader.
This function can be used to monitor functions via the PLC if trigger signals and
reading of data cannot occur simultaneously for application-related reasons.
Correlation must take place in the PLC.
=
0 (00000000b) channel 0 of the R/W head
=
1 (00000001b) channel 1 of the R/W head
=
2 (00000010b) channel 2 of the R/W head
1)
: transmits the trigger signal to the control unit
=
0 (00000000b) trigger mode switched off
=
1 (00000001b) trigger mode switched on
=
2 (00000010b) trigger mode inverted
1)
53
