IC-KP2-2HB18-2V1
Commands
CC-Link version
Version 1.1 and
Version 2 - single
extension
Version 2 - dual
extension
Version 2 -
quadruple
extension
Version 2 - octuple
extension
The R/W head makes attempts until successful, to read <WordNum> 32-bit words
from the address <WordAddr>. Only modified data is transferred via the interface.
When a read/write tag leaves the detection range, the status '05h' (read
command) is output.
Maximum word count
<WordNum> <= 3 (0000 0011b)
<WordNum> <= 7 (0000 0111b)
<WordNum> <= 7 (0000 0111b)
<WordNum> <= 15 (0000 1111b)
<WordNum> <= 15 (0000 1111b)
<WordNum> <= 31 (0001 1111b)
<WordNum> <= 31 (0001 1111b)
<WordNum> <= 63 (0011 1111b)
Transmission
per channel with parallel
transfer of channels 1 & 2
per channel with transfer of
channel 1
per channel with parallel
transfer of channels 1 & 2
per channel with transfer of
channel 1
per channel with parallel
transfer of channels 1 & 2
per channel with transfer of
channel 1
per channel with parallel
transfer of channels 1 & 2
per channel with transfer of
channel 1
59
