IC-KP2-2HB18-2V1
Commands
Write command enhanced without split data
ID command execution request (RYn4)
ID division data request (RXn7)
ID division data complete (RYn7)
ID command complete (RXn4)
ID in zone contact (RXn2)
ID error occurrence (RXn5)
Figure 7.11
Write command enhanced with split data
behaves as a write command single with split data
Troubleshooting, RYn3 as confirmation
Figure 7.12
writing cmd and data
to RWw
PLC program
ID BUSY (RXn3)
ID data ack (RYn3)
Tag communication
PLC program
ID command execution request (RYn4)
ID BUSY (RXn3)
ID division data request (RXn7)
ID division data complete (RYn7)
ID command complete (RXn4)
ID data ack (RYn3)
ID in zone contact (RXn2)
ID error occurrence (RXn5)
Tag communication
reading response
reading response
from RWr
from RWr
writing cmd
reading response
to RWw
from RWr
43
