IC-KP2-2HB18-2V1
Commands
Note!
The addresses for the start and end of the read range are based on the absolute
word address of the read/write tag, not on <WordAddr>.
Example: With the setting read range start 03h and read range end 03h, the R/W
head only reads the first data word in the read/write tag.
Setting "Default Read"
1. Activate the password mode.
2. Write the read range start and end into the "Control Word".
3. Deactivate the password mode.
4. Read the data range with address designation 0000h and word count 0h.
IPC03 Configuration
The storage of a data carrier IPC03 is organized by word. A data word is defined
with a length of 32 bits. For the normal data range, 29 words from addresses 3
through 31 (<WordAddr> = 00h ... 1Ch) are available.
Address
Word 0
Word 1
Word 2
Word 3 ...31
Word 32
Word 33
Word 0 contains the password. The password can only be written.
With word 1, the "Protection Word", you can define a read-protected and a write-
protected range. The "Protection Word" can only be read and written with the
correct password.
With word 2, the "Control Word", you can set various operating modes and the
read range for the operating mode "Default Read". The "Control Word" can only
be read and written with the correct password.
If you would like to use the "Protection Word" and the "Control Word", you must
first activate the password mode.
Meaning <WordAddr> <ConfAddr>
Password
Protection word
Control word
Data range 00h ... 1Ch
Device Serial Number
Device identification
- -
- 1
- 2
-
1Dh -
1Eh -
Note
Write only
Read/write
Read/write
Read/write
Read only
Read only
