IC-KP2-2HB18-2V1
Commissioning
6.2.2

Baud rate setting

The IDENTControl Compact supports five different baud rates:
Switch setting
0
1
2
3
4
5-9
Set the desired baud rate via thebaud rate rotary switch on the reverse of the
device.
Note!
The setting of the baud rate is only read during the start process. An alteration of
the switch during operation makes no alteration to the configuration of the
IDENTControl control interface. If you change the baud rate during operation, LED
L ERR flashes red. To apply the changes, switch the device off and back on again.
6.2.3

Extended cyclic setting

The IDENTControl Compact supports five different extended cycle settings:
Switch setting
0
1
2
4
8
3, 5-7, 9
Set the desired number of cycles via theextended cyclic setting rotary switch on
the reverse of the device.
Note!
The extended cyclic setting is only read during the start process. An alteration
of the switch during operation makes no alteration to the configuration of the
IDENTControl control interface. To apply the changes, switch the device off and
back on again.
Baud rate
156 kbit/s
625 kbit/s
2.5 Mbit/s
5 Mbit/s
10 Mbit/s
-
CC-Link version
CC-Link V1.10
CC-Link V2
CC-Link V2
CC-Link V2
CC-Link V2
CC-Link V1.10
Extended cyclic setting
-
single = 1 telegram / response
2-way = 2 telegrams / response
4-way = 4 telegrams / response
8-way = 8 telegrams / response
no division
23
