This command is the same as a normal write command. The data is write-
protected at the end of the write process, provided the tags offer this function.
This applies for 13.56 MHz tags of the type 21, 22, 24, and 33 as well as for LF
tags IDC-...-1K. Write protection is only activated for memory blocks involved in
the write process. Data can continue to be written to all other memory blocks.
The R/W head makes one attempt to write <WordNum> 32-bit words from the
address <WordAddr>.
Enhanced write words with lock (EL -->48h)
Master -> Slave
Address
CH1
RWw n
RWw n+1
RWw n+2
RWw n+3
RWw n+4
RWw n+5
RWw n+6
RWw n+7
RWw n+8
RWw n+9
RWw n+A
RWw n+B
80
Maximum word count
<WordNum> <= 3 (0000 0011b)
<WordNum> <= 7 (0000 0111b)
<WordNum> <= 7 (0000 0111b)
<WordNum> <= 15 (0000 1111b)
<WordNum> <= 15 (0000 1111b)
<WordNum> <= 31 (0001 1111b)
<WordNum> <= 31 (0001 1111b)
<WordNum> <= 63 (0011 1111b)
Bit no.
CH2*
15
RWw n+8
<WordNum>
RWw n+9
<WordAddr> low byte
RWw n+A
<Write data> byte 2
RWw n+B
<Write data> byte 0
RWw n+C
<Write data> byte 2
RWw n+D
<Write data> byte 0
RWw n+E
<Write data> byte 2
RWw n+F
<Write data> byte 0
<Write data> byte 2
<Write data> byte 0
<Write data> byte 2
<Write data> byte 0
Transmission
per channel with parallel
transfer of channels 1 & 2
per channel with transfer of
channel 1
per channel with parallel
transfer of channels 1 & 2
per channel with transfer of
channel 1
per channel with parallel
transfer of channels 1 & 2
per channel with transfer of
channel 1
per channel with parallel
transfer of channels 1 & 2
per channel with transfer of
channel 1
8
7
0
1
0
0
1
0
<WordAddr> high byte
<Write data> byte 3
<Write data> byte 1
<Write data> byte 3
<Write data> byte 1
<Write data> byte 3
<Write data> byte 1
<Write data> byte 3
<Write data> byte 1
<Write data> byte 3
<Write data> byte 1
0
0
0
