5.3.5 OR
Fashion:
The output of an OR is 1 if at least one input is 1 (closed).
A block input that is not used (x) is assigned: x = 0.
Logic table of the OR function:
Input 1
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
71
Classic:
Input 2 Input 3
0 0
0 0
0 1
0 1
1 0
1 0
1 1
1 1
0 0
0 0
0 1
0 1
1 0
1 0
1 1
1 1
(Symbol in xLogic)
Input 4 Output
0 0
1 1
0 1
1 1
0 1
1 1
0 1
1 1
0 1
1 1
0 1
1 1
0 1
1 1
0 1
1 1
