Power supply:
Nominal voltage
Operating limits
Immunity from micro
power cuts
Max. Startup current
Max. absorbed power
Protection against polarity
inversions
The main frequency range
Input parameters:
Input No
Digital input
Analogue input
Input voltage
Input signal0
Input signal1
Input current
Input Response Time
Maximum counting
frequency
Sensor type
Isolation between power
supply and inputs
Isolation between inputs
Protection against polarity
inversions
Inputs used as analog inputs( I1-I4 )
Measurement range
Input impedance
Input voltage
Resolution
Accuracy at 25 °C
Accuracy at 55 °C
Isolation between analog
387
AC110V-240V DC 12-24V
AC85 - 265 V DC 10.8-28.8V
--- Typ. 5 ms
--- Max. 0.25A
34mA (85V ac) ; 1.1 W (10.8V dc) ;
26mA (265V ac) 1.2 W (28.8V dc)
Yes Yes
47-63Hz ---
4 ( I1-I4 ) 4 (I1-I4 )
4 ( I1-I4 ) 4 (I1-I4 )
None 4 ( I1-I4)(0..10V DC)
AC0-240V DC 0-28.8V
AC0-40V；<0.03mA < 5V DC;<0.1mA(I1-I4),<1mA(I5-I8)
AC79-240V;>0.06mA > 8 V DC;>0.3mA(I1-I4),>1.7mA(I5-I8)
--- 0.4mA(I1-I4),2.3mA(I5-I8),@ 10.8V dc
0.5mA(I1-I4),2.6mA(I5-I8),@ 12.0 V dc
1.2mA(I1-I4),5.2mA(I5-I8),@ 24 V dc
1.5mA(I1-I4),6.3mA(I5-I8),@ 28.8 V dc
Delay time at 0 to 1： Delay time at 0 to 1 ：
120V AC ：Typ. 50 ms Typ. 1.5 ms (I1-I4),<1ms(I5-I8)；
240V AC ：Typ. 30 ms Delay time at 1 to 0 ：
Delay time at 1 to 0： Typ. 1.5 ms(I1-I4),<1ms(I5-I8)；
120V AC ：Typ. 90 ms
240V AC ：Typ.100 ms
Typ. 4Hz Typ.：4 HZ
Contact or 3-wire PNP Contact or 3-wire PNP
None Resistive
None None
Yes None
--- DC 0---10V
--- Min, 24KΩ ; Max. 72KΩ
--- 28.8 V DC max
--- 9bit ,0.015V
--- ± (Max.0.02)V
--- ± (Max.0.04)V
--- None
