5.9 Basic Operation

This chapter will tell you how to write logic function graph Program with xLogicsoft, how to simulate the
Program you write with xLogicsoft, how to communicate between PC and xLogic with xLogicsoft, how to
copy system document of xLogic with xLogicsoft, and how to complete the update of application and
system Program code. If you want to write a function graph Program, first of all, it's necessary to start an
empty document, and then put the function block into editing box. First set the property of every function
block, then link every function block according to logic controlling relation, thereby complete the
protracting of a logic function graph. In addition, in order to help the users confirm if the function graph
accord with the prospective controlling result, xLogicsoft also provides most intuitionist function of
simulation. You can get the moving result of the program through simulation of the function graph.

5.9.1 Open File

5.9.1.1 Open New File

Operation method:
To open a new file, click 'New' option of menu 'File', click once with left button of mouse. As shown in the
following fig.
