Chapter 7 Applications; Dual-Function Switch; Standard Solution - Rievtech xLogic ELC Series User Manual

In order to let users know the far going application field of xLogic, we present a set of application example.
Each instance includes the circuit program of its original solution and the compare of solution in which
xLogic has been applied.
You can find the following solution:

Dual-function switch

Automatic gate
Ventilation system
Industry door
Daylight lamps
Rain water pump
Note:
The application example of xLogic is available free of charge to our clients, but we can't make any
promise, it is only to explain the general rule of using xLogic. It is possible that these instances can be
different from user's specific application, so user should take all related responsibility of running those
instance systems, and we sincerely suggest user shall refer to relevant nation standard and installation
rules related to systems. Also, we have to point out that error is unavoidable, and we reserve the
according modification rights.
7.1 Dual-function switch
Requirements for stairway lighting systems
The basic requirements for a stairway lighting system are as follows:
When someone is using the stairs, the stairway lights should be on.

If no one is in the stairway, the lights should go out in order to save energy.


7.1.1 Standard solution

335

Chapter 7 Applications
