Output AQ
Parameter P (number of decimal places)
Only applies for portraying the values from PV, SP, Min. and Max. in a message text.
Timing Diagram
The nature, manner and speed with which the AQ changes depends on the parameters KC and TI. Thus,
the course of AQ in the diagram is merely an example. A control action is continuous; therefore the
diagram portrays just an extract.
A: Gain
Value range: +- 10.00
B: Offset
Value range: +- 10,000
SP: Set-value
value range: -10,000 to +20,000
Mq:
Value from AQ
Value range: 0 to 1,000
Parameter sets: application-related presets for KC, TI
and Dir (see below)
KC:
value range: 00.00 to 99.99
TI: Integral
value range 00:01 min to 99:59 min
Dir: Action direction
value range: + or -
p:
Number of
value range: 0, 1, 2, 3
Analog output (manipulated variable)
Value range for AQ: 0 to 1,000
assignment
with manual mode.
Gain
time
of the controller
decimal places
