Protection against polarity
inversions
The main frequency range
Input parameters:
Input No
Digital input
Analogue input
Input voltage
Input signal0
Input signal1
Input current
Input Response Time
Maximum counting
frequency
Sensor type
Isolation between power
supply and inputs
Isolation between inputs
Protection against polarity
inversions
Inputs used as analog inputs( I1-I4 )
Measurement range
Input impedance
Input voltage
Resolution
Accuracy at 25 °C
Accuracy at 55 °C
Isolation between analog
channel and power supply
Cable length
Output parameters:
Output No.
Output type
Continuous current
385
35mA (265V ac)
Yes
47-63Hz
8 ( I1-I8 )
8 ( I1-I8 )
None
AC0-240V
AC0-40V；<0.03mA
AC79-240V；
>0.06mA
---
Delay time at 0 to 1：
120V AC ：Typ. 50 ms
240V AC ：Typ. 30 ms
Delay time at 1 to 0：
120V AC ：Typ. 90 ms
240V AC ：Typ.100 ms
Typ. 4Hz
Contact or 3-wire PNP
None
None
Yes
---
---
---
---
---
---
---
---
4 (Q1-Q4)
Relay output
Resistive load 10A/Inductive load 2A (Relay)
4 W (28.8V dc)
Yes
---
8 (I1-I8 )
8 (I1-I8 )
4 ( I1-I4)(0..10V DC)
DC 0-28.8V
< 5V DC;<0.1mA(I1-I4),<1mA(I5-I8)
> 8 V DC;>0.3mA(I1-I4),>1.7mA(I5-I8)
0.4mA(I1-I6),2.3mA(I7-IC),@ 10.8V dc
0.5mA(I1-I6),2.6mA(I7-IC),@ 12.0 V dc
1.2mA(I1-I6),5.2mA(I7-IC),@ 24 V dc
1.5mA(I1-I6),6.3mA(I7-IC),@ 28.8 V dc
Delay time at 0 to 1 ：
Typ. 1.5 ms (I1-I4),<1ms(I5-I8)；
Delay time at 1 to 0 ：
Typ. 1.5 ms(I1-I4),<1ms(I5-I8)；
Typ.：4 HZ
Contact or 3-wire PNP
Resistive
None
None
DC 0---10V
Min, 24KΩ ; Max. 72KΩ
28.8 V DC max
10bit ,0.01V
± (Max.0.02)V
± (Max.0.04)V
None
10 m max. shielded and twisted
