Chapter 6 How to configure the Ethernet CPU ?

There are 2 different Ethernet configuration method for old and new series Ethernet CPU. For the new one,
you can refer to chapter 6.1--6.6. For the old one, please refer to chapter 6.7--6.9

6.1 How to separate the new version and old version?

New functions for Ethernet PLC from Rievtech is released.
Included CPU models:
ELC-12DC-DA-R-N
EXM-12DC-DA-R-N(-4G)
Method A:
Label on the bottom of the plastic house of the CPU. The new version marked with "V2" following the
model.
Method B:
Get the version number by the software menu Tools-> transfer-> Get PLC version
If the hardware version is 1, that means it is new version.
Difference between 2 versions:
Items
Network parameters
251
New version
Program software(xlogicsoft or
Old version
DeviceManager software
