channel and power supply
Cable length
Output parameters:
Output No.
Output type
Continuous current
Max. breaking voltage
Max. Allowable Power Force
Electrical durability
Expectancy
Mechanical life
Response time
Built-in protections
Switch frequency:
Mechanism
Resistor/light load
Sensitive load
Other parameters:
Weight
Connection cables
Ambient temperature
Storage temperature
Certification
Mounting
Dimensions
Extension Units for
Ethernet CPU(ELC-12-N)
(EXM-E series)
Power supply:
Nominal voltage
Operating limits
Immunity from micro
power cuts
Max. Startup current
Max. absorbed power
Protection against polarity
inversions
Input parameters:
Input No
Digital input
--- 10 m max. shielded and twisted
4 (Q1-Q4)
Relay output
Resistive load 10A/Inductive load 2A (Relay)
AC 250 V /DC 110 V(Relay)
1250VA /300W(Relay)
10 5 Operations at Rated Resistive Load(Relay)
10 Operations at No Load condition(Relay)
7
---
Operate Time : 15 mSec. Max.(Relay)
Release Time : 10 mSec. Max.(Relay)
Against short-circuits: None
Against overvoltages and overloads: None
10Hz
2Hz
0.5Hz
Approx.250g
2 x 1.5 mm² or 1 x 2.5 mm²
-20 to + 55 ºC
–40 ºC to + 70 ºC
CE
On 35 mm standard mounting rail, 4 MW, or wall-mounting
W x H x D (48*90*64 mm)
EXM-E-AI-I EXM-E-PT100
DC 12-24V
DC 10.8-28.8V
Typ. 5 ms
Max. 0.25A
3.5 W (10.8V dc) ; 4.5 W (28.8V dc)
Yes
4 ( I1-I4 ) 2 PT100
None None
EXM-E-AQ-V EXM-E-AQ-I
DC 24V DC 12-24V
DC 15-28.8V DC 10.8-28.8V
---
---
