Analogue input
Analog inputs
Measurement range
Resolution
Accuracy at 25 °C
Isolation between analog
channel and power supply
Cable length
Output parameters:
Output No.
Output type
Resolution
Accuracy at 25 °C
Other parameters:
Weight
Short-circuit protection
Connection cables
Ambient temperature
Storage temperature
Certification
Mounting
Dimensions
RS485 communication module
for ELC-12-N Ethernet CPU
(EXM-E-RS485)
Power supply:
Nominal voltage
Operating limits
Immunity from micro power cuts
Max. Startup current
Max. absorbed power
Protection against polarity inversions
Input parameters:
None
Output parameters:
None
Other parameters:
Weight
Short-circuit protection
Connection cables
Ambient temperature
389
I1-I4(0/4...20mA) 2PT100
0/4...20mA -50℃--200℃
0.5℃
0.02mA
Max. 0.05mA < 1 ℃
None None
10 m max. shielded and twisted
---
---
---
---
Approx.250g
External fuse required
2 x 1.5 mm² or 1 x 2.5 mm²
-20 to + 55 ºC
–40 ºC to + 70 ºC
CE
On 35 mm standard mounting rail, 4 MW, or wall-mounting
W x H x D (48*90*64 mm)
EXM-E-RS485
DC 12-24V
DC 10.8-28.8V
Typ. 5 ms
Max. 0.1A
1.5 W (10.8V dc) ; 1.8W W (28.8V dc)
Yes
Approx.250g
External fuse required
2 x 1.5 mm² or 1 x 2.5 mm²
-20 to + 55 ºC
---
---
---
---
2(AQ1-AQ2)
0...10V 0...20mA
0.01V 0.02mA
0.02V 0.05mA
