Input signal0
Input signal1
Input current
Input Response Time
Maximum counting
frequency
Sensor type
Isolation between power
supply and inputs
Isolation between inputs
Protection against polarity
inversions
Inputs used as analog inputs( I1-I4 )
Measurement range
Input impedance
Input voltage
Resolution
Accuracy at 25 °C
Accuracy at 55 °C
Isolation between analog
channel and power supply
Cable length
Output parameters:
Output No.
Output type
Continuous current
Max. breaking voltage
Max. Allowable Power Force
Electrical durability
Expectancy
Mechanical life
Response time
Built-in protections
Switch frequency:
AC0-40V；<0.03mA
< 5V DC;<0.1mA(I1-I4),<1mA(I5-I8)
AC79-240V;>0.06mA > 8 V DC;>0.3mA(I1-I4),>1.7mA(I5-I8)
--- 0.4mA(I1-I4),2.3mA(I5-I8),@ 10.8V dc
0.5mA(I1-I4),2.6mA(I5-I8),@ 12.0 V dc
1.2mA(I1-I4),5.2mA(I5-I8),@ 24 V dc
1.5mA(I1-I4),6.3mA(I5-I8),@ 28.8 V dc
Delay time at 0 to 1： Delay time at 0 to 1 ：
120V AC ：Typ. 50 ms Typ. 1.5 ms (I1-I4),<1ms(I5-I8)；
240V AC ：Typ. 30 ms Delay time at 1 to 0 ：
Delay time at 1 to 0： Typ. 1.5 ms(I1-I4),<1ms(I5-I8)；
120V AC ：Typ. 90 ms
240V AC ：Typ.100 ms
Typ. 4Hz Typ.：4 HZ
Contact or 3-wire PNP Contact or 3-wire PNP
None Resistive
None None
Yes None
--- DC 0---10V
--- Min, 24KΩ ; Max. 72KΩ
--- 28.8 V DC max
--- 9bit ,0.015V
--- ± (Max.0.02)V
--- ± (Max.0.04)V
--- None
--- 10 m max. shielded and twisted
8 (Q1-Q8)
Relay output
Resistive load 10A/Inductive load 2A (Relay)
AC 250 V /DC 110 V(Relay)
1250VA /300W(Relay)
10 5 Operations at Rated Resistive Load(Relay)
10 7 Operations at No Load condition(Relay)
Operate Time : 15 mSec. Max.(Relay)
Release Time : 10 mSec. Max.(Relay)
Against short-circuits: None
Against overvoltages and overloads: None
8 (Q1-Q8)
Transistor output
0.3A(Transistor)
DC 30V(Transistor)
9W(Transistor)
---
---
Operate Time : <1 ms
Release Time : <1 ms
